Water Heating Elements
Straight Water Heating Element (mod.RT)
Sheat | Pipe Development | ||
---|---|---|---|
W | V | mm | |
1000 | 220 | 280 | 600 |
1200 | 220 | 280 | 600 |
1500 | 220 | 280 | 750 |
2000 | 220 | 280 | 1800 |
2500 | 220 | 280 | 1160 |
3000 | 220 | 280 | 1490 |
> 1" 1/4 Brass screw pipe connection
> Copper pipe 8.5 mm diameter
![RTS-HW-101-3](http://www.samarli.com/wp-content/uploads/2018/03/RTS-HW-101-3-2.jpg)
Bent Water Heating Element (mod.RTC)
![RTS-HW-101-4](http://www.samarli.com/wp-content/uploads/2018/03/RTS-HW-101-4.jpg)
Sheat | Pipe Development | ||
---|---|---|---|
W | V | mm | |
1000 | 220 | 280 | 600 |
1200 | 220 | 280 | 600 |
1500 | 220 | 280 | 750 |
2000 | 220 | 280 | 1800 |
2500 | 220 | 280 | 1160 |
3000 | 220 | 280 | 1490 |
> 1" 1/4 Brass screw pipe connection
> Copper pipe 8.5 mm diameter
Straight Flange Type Water Heating Element (mod.RF)
Sheat | Pipe Development | ||
---|---|---|---|
W | V | mm | |
1000 | 220 | 280 | 600 |
1200 | 220 | 280 | 600 |
1500 | 220 | 280 | 750 |
> Flange pipe connection
> Copper pipe 8.5 mm diameter
![RTS-HW-101-5](http://www.samarli.com/wp-content/uploads/2018/03/RTS-HW-101-5.jpg)
Bent Flange Type Water Heating Element (mod.RFC)
![RTS-HW-101-6](http://www.samarli.com/wp-content/uploads/2018/03/RTS-HW-101-6.jpg)
Sheat | Pipe Development | ||
---|---|---|---|
W | V | mm | |
1000 | 220 | 280 | 600 |
1200 | 220 | 280 | 600 |
1500 | 220 | 280 | 750 |
> Flange pipe connection
> Copper pipe 8.5 mm diameter
